| SUNZUKI: Electric
Samurai, a 4 wheel drive electric vehicle capable of climbing 45
degree slopes with total control and ease. Forget trying to keep your foot
on the gas, the brake, and slip the clutch; you can't stall this machine.
maximum torque is at 0 rpm making this one of the most capable rock crawlers
ever. Suspension has been completely upgraded for more load capacity, 6"
more travel, smoother than stock ride, with about 2" to 3 " of
lift. . |
 |
| Purpose, uses |
ranch patrol, rock crawler, &
around town |
| weight |
2900 lbs |
| top speed |
65 mph |
| range |
40 miles @ 35 mph, 25 miles @
50 mph |
| Motor ,hp |
9" Advanced DC series wound
motor, 100 HP peak |
| Controller |
600 Amp Raptor from DC Power |
|
| Charger |
K & W 20 Amp
Charger, with temperature compensation |
| Batteries, AH, # |
36 - B & B EB-50
Sealed deep cycle 12 volt 50 AH batteries |
| System Voltage |
144 V (up to 156 available) |
| DC/DC converter |
DC Power 144 to 12 volt w/ 18
AH sealed battery for vehicle electric, lights, etc. |
| Additional Electric features |
electric heater with original
suzuki style control switches
electric vacuum pump system for power brakes, with manual override for stealth
mode |
| Suspension |
Rocky Road JP eater conversion
kit: all new spring mounts, shock mounts (bolted & MIG welded), YJ
Wrangler leaf springs, Bilstein Shocks, Poly bushings, 2" lift front,
3 inch in back. 6" more wheel travel, improved weight capacity (for
batteries) and smoother than stock ride. |
| Tires |
BF Goodrich 235/75R-15 All Terrain
Radials at 50 psi (same rolling resistance as stock tires) |
| Seating |
2+2. Observation
height rear seating relocated higher to accomodate batteries & folds
up for carrying gear. |
| Extras |
Shrockwerks winch
mount front bumper & guard |
| Metering |
E-Meter Electric
system Status Meter w/ high voltage adapter, Tachometer w K&W converter,
Inclinometer |
 |
Available
Options |
8000 lb winch,
Alpine tape & CD stereo w/ Boston Acoustic Speakers,
Locking Front & Rear Differentials
Onboard Air supply
Onboard Power inverter for power tools & AC appliances
Portable Yamaha quiet generator for remote charging
Solar charging station |
